Details
Application: Industrial equipment
Order No.: 61907
Weight: 15.4 kg
Remarks: With bead rings, 48mm bolts, nuts and washers
Cross references
ContiTech: FD2870-30 M10
ContiTech Order No.: 61907
Firestone No.: W01M586978
Firestone Bellows No.: 215 [CN / GB]
Firestone New Bellows No.: 215C
Torques
M10: max. 40 Nm
Original parts
–
Download
FD_2870-30_RS_CN.pdf
FD_2870-30_RS_GB.pdf
FD_2870-30_RS_DE.pdf
详情
应用: 工业设备
订货编号: 61907
重量: 15.4 kg
备注: 带铝制压边圈（又译卡环，俗称法兰），长度为 48mm 螺栓，带螺母及垫片
相互参照
ContiTech: FD 2870-30 M10
ContiTech Order No.: 61907
Firestone No.: W01-M58-6978
Firestone Bellows No.: 215 [CN / GB]
Firestone New Bellows No.: 215C
扭矩
M10: max. 40 Nm
原始部件
–
下载
FD_2870-30_RS_CN.pdf
FD_2870-30_RS_GB.pdf
FD_2870-30_RS_DE.pdf
评价
目前还没有评价
